mmcs20-31a
MOLIMED color scan
  • Automatic color scan
  • Manual interrupt of the color scan
  • Manual jump to the next or previous color
  • Preset colors for color-puncture use
  • Clean colors in the visible spectrum
  • Makes mixed colors
  • Handy device for professional use
  • Accessories compatible to the MOLIMEDpen color light system

MOLIMED color scan

In the MOLIMED color scan device, the three base-colors RED, GREEN and BLUE are generated with three LED’s.
Most of the color-shapes in the visible spectrum can be generated by change of the brightness of the three base-colors.

Priority on color sequences

  • the color puncture mode
  • the complementary color mode
  • the color scan mode

Color scan mode

Colors are changing automatically with the color-scan function. The scan can be stopped and restarted.

Accessories

For the MOLIMED color scan, the same accessory parts can be used as for the MOLIMEDpen.
Further colors like indigo 528, violet or deep red cannot be generated with MOLIMED color scan but can be supplemented with MOLIMEDpen.

!
MMCS17
Weight: kg

MOLIMED color scan 17

The base model of the color scan series

The MOLIMED color scan 17 contains the 8 basic colors for beginners and private users.

There is no scan through the rainbow colors possible.

The colors and the application are explained in the book of Dr. Pagnamenta "Children in the light".

The following colors are selectable: red - orange - yellow - green - turquoise - indigo - violet - pink.
With color scan 17, no automatic color conduit is possible.

MMCS35
Weight: kg

MOLIMED color scan 35

The model with priority for color puncture and the color scan mode

Functions
MOLIMED color scan 35 is the base model of the color scan series color puncture mode and color scan.

After power on, the color puncture mode is selected. All the predefined colors mainly used for color puncture can be selected by clicking the NEXT COLOR or PREV COLOR switch. The following color sequence is predefined: red - orange - yellow - green - blue - indigo - violet - turquoise - light green - purple - pink - light-gray - middle-gray - dark-gray.

The automatic color-scan-mode with color stop and go can simply be selected by clicking the SCAN switch. The following color sequence is predefined in the color scan mode: red - yellow - yellow-green - green - turquoise - blue - indigo - violet - purple - pink - white - light-green - orange - red.

MMCS40
Weight: kg

MOLIMED color scan 40 HI

The High Intensity model of the color scan series

Functions

The MOLIMED color scan 40 is the hight intensity model of the color scan series. The light is up to 4 times stronger then in the color scan 35 and color scan 50 models and can be even more intense than the MOLIMEDpen light.

The predefined colors of the color puncture mode and the color-scan mode are the same as in the color scan 35.

The higher intensity of the light needs more power. Therefore an accumulator with higher capacity is built in.

MMCS52
Weight: kg

MOLIMED color scan 52

The top model of the color scan series with infrared and ultraviolet light

Functions

After power on, the color puncture mode is selected. All the predefined colors mainly used for color puncture can be selected by clicking the NEXT COLOR or PREV COLOR switch. The following colors sequence is predefined: red - orange - yellow - green - blue - indigo - violet- turquoise - light green - purple - pink - light-gray - middle-gray - dark-gray - infrared 950 - ultraviolet 370.

The automatic color-scan-mode with color stop and go can simply be selected by clicking the SCAN switch. The following color sequence is predefined in the color scan mode: red - yellow - yellow-green - green - turquoise - blue - indigo - violet - purple - pink - white - light-green - orange - red. Infrared, ultraviolet and the gray colors can only be selected in the color puncture mode.

MMCS62
Weight: kg

MOLIMED color scan 62

The color scan with priority on the complementary colors

Functions

After power on, the complementary colors mode is selected. All the predefined colors can be selected by clicking the NEXT COLOR or PREV COLOR switch. Following colors are preset: green - magenta, citrus - violet, yellow - blue, orange - indigo, scarlet - cyan, red - turquoise.

The automatic color-scan-mode with color stop and go can simply be selected by clicking the SCAN switch. The sequence of the colors is the same as in the color scan 35 and 40.

Delivery

  • MOLIMED color scan
  • universal charger with euro plug and cable (100-240 VAC)
  • carry bag
  • owner’s manual

Accessories must be ordered separately. World power adapter available as accessory part.

Specifications

wavelength - luminous intensity (approximate max. levels)

Model 17 / 35 / 52 / 62: red 625nm - 1'800mcd, green 528nm / 2'200mcd, blue 470nm / 630mcd
Model 52 additionally: uv 370nm / 13mW/sr, ir 950nm / 40 mW/sr
Model 40: red 625nm / 4’000mcd, green 528nm / 6’400mcd, blue 465nm / 2’000mcd

dimensions (WxLxH)

2.5 x 5.9 x 0.9 inch (65 x 150 x 24 mm)

weight

2.5 oz. (70 gr)

color

creme

power supply

Model 17 / 35 / 52 / 62: Li-Ion Accu 3,7 Volt / 450 mA/h
Model 40: Li-Ion Akku 3,7 Volt / 1’200 mA/h

power consumption

Model 17 / 35 / 62: 40 mA max.
Model 52: 120 mA max.
Model 40: 320 mA max.

warranty

 24 months on material and repair work
